Launch X431 Pro Mini Bluetooth With 2 Years Free Update Online Powerful Than Diagun

Launch X431 Pro Mini Bluetooth With 2 Years Free Update Online Powerful Than Diagun

X431 Pro Mini Description:

X431 PRO MINI is a stylish Android-based vehicle trouble diagnostic tool. It inherits from Launch’s advanced diagnosing technology and is characterized by covering a wide range of vehicles, featuring powerful functions, and providing precise test result.

Language: Arabic, Polish, German, Russian, French, Finish, Dutch, Czech, Norwegian, Portuguese, Japanese, Swedish, Spanish, Italian, English, Denish, Korea
X431 PRO MINI Update: One-Click Free Update Online for 2 Years, when free update expired, update cost will be $399 for one year and $599 for two years.

Launch X431 Pro Mini Features:

1.Support multi-brand manufacturers,multi-functions and special functions
2.One-click Update
3.Provides automotive handbook, repair case and wiring diagrams.
4.Configures I/M tool enables exchange repair experience and perform remote assistance.
5.Browser: built-in Wi-Fi module makes surfing on the internet freely.
6.Email: allows you to send and receive emails.
7.Settings: to configure your personalized X-431 PRO MINI through it.
8.Applications: other Android based applications can be customized to install or uninstall.

Launch X431 Pro Mini Special Functions:

Oil Reset Service
Steering Angle Calibration
Electronic Parking Brake Reset
Battery Register / Battery Maintenance
ABS Bleeding
Electronic Throttle Position Reset / Learn
Diesel Particulate Filter (DPF) Regeneration
Tire Pressure Monitor System Reset
Gear Learning
Immobilizer Matching
Fuel Injector Coding


Launch X431 Pro Mini Reset Function:

Oil Light Reset all you to reset the service lamps on the instrument cluster
EPB Service allows you to perform the service and maintenance of brake systems
ABS Bleeding keeps the tires from locking up immediately when they are brakes,causing rollovers and other condition
Battery Registration helps you reset the vehicle life after you replace the battery to ECU to work properly
Tire Pressure Monitor System Reset let you TPMS more safer and concise.
Gear Learning allow to relearn the communication of Gear Position information
Anti-theft matching lets you to start and drive vehicle successfully
DPF(diesel particulate filter) Regeneration lets you erform the DPF cleaning.
SAS Calibration function lets you perform calibration of the Steering Angle Sensor

Actuation Test Launch x431 pro mini support Actuation Test, it can send information to and receive information from a vehicles control module.	ECU Coding Launch x431 pro mini support ECU Coding , if you replace a new ECU for car, x431 v can help you code it. It is very useful for mechanic.	Injector Coding Sometimes, car need to change a new injector, pro mini can help you code new injector.

Launch X431 Pro Mini Vehicle Models List:

X-431 PRO MINI supports all electronic control systems on 12V EFI models, incl. more than 150 European, American and Asian models like Maserati, Ferrari, Rolls Royce, Bentley, Mercedes-Benz, BMW, Audi.Diagnose the electronic control system of prevailing vehicle models covering Asian, European, American and Chinese. It achieves full car model and full system vehicle trouble diagnosis

Software	Car Brand	Software	Car Brand	Software	Car Brand	Software	Car Brand
1	CHANGCHENG	28	BXGM	55	KIA	82	CHANGHE
2	DAEWOO	29	SPARK TY	56	Renault	83	FIAT
3	HUACHEN	30	USAFORD	57	Skoda	84	SAICMG
4	FORD(AU)	31	Peugeot	58	SPRINTER	85	MAZDA
5	ZHONGXING	32	SUZUKI	59	ROVER	86	ZHONGTAI
6	AUTOSEARCH	33	RESETOIL	60	WEILI	87	JAGUAR
7	RESETSAS	34	PROTON	61	INDIANMARUTI	88	Opel
8	BAIC	35	AST ONMARTIN	62	INDIANMAHINDRA	89	VOLVO
9	INDIANTATA	36	RESETIMMO	63	PERODUA	90	Chrysler
10	SAIPA	37	UAZ	64	AUSTHOLDEN	91	DAIHATSU
11	DEMO	38	ZAZ	65	RESETINJEC	92	FLYER
12	JACTY	39	PAZ	66	BUGATTI	93	HMAZDA
13	MARUTI	40	LUXGEN	67	RESETTPMS	94	Hyundai
14	PERODUA	41	TOYOTA	68	EOBD2	95	PROTON
15	VAZ	42	VW	69	HAFEI	96	Subaru
16	Porsche	43	CHANGAN	70	HAOQING	97	SSANGYONG
17	QIRUI TY	44	Audi	71	LIFAN	98	JOYLONG
18	RESETBRAKE	45	CITROEN	72	MAHINDRA	99	FERRARI
19	SAMSUNG	46	DFXK	73	Nissan	100	SEAZ
20	ECUAID	47	FUTIAN	74	XIALI	101	HOLDEN
21	MASERATI	48	HONDA	75	ZHONGHUN	102	Mitsubishi
22	RESETGEAR	49	LANDROVER	76	TATA	103	SAAB
23	BMW	50	LIUWEI TY	77	TRUMPCHI	104	GAZ
24	GM	51	XINKAI	78	RESETBMS	105	JIAO
25	Seat	52	BXFIAT	79	AUSTFORD	106	RESETBLEED
26	Isuzu	53	Smart	80	IZH	107	RESETET

What is the Different Between Launch X431 Pro Mini and X431 Pro?

No.	ITEM	Launch X431 Pro Mini	X431 Pro
1	Picture
2	Software	PROS(Free Upgrade for 2 years)	Pro
3	System	Android 5.1	Android 4.2
4	Screen size	6.8 inch	7 inch
5	Size(L*W*H)	205.2x110.7*40.0mm	198*124*10.1mm
6	Weight	0.5kg	0.64kg
7	Screen resolution	1280*720	1.3GHz Quad Core
8	Processors	1.3 GHz Quad Core	1GB
9	RAM	2GB	1G
10	Hard disk	16GB (TF card 64g)	8GB Expandable to 32G
11	Battery	3000mAh	3000mAh
12	Diagnostic Software	108 cars	108 cars
13	Diagnostic Mode	Bluetooth	Bluetooth
14	Upgrade Mode	Online One-click upgrade	Online One-click upgrade
15	Cemera	Rear 500Mic+front 200Mio	Rear 30Mio+front 320Mio
16	USED as a pad	Y	Y
17	Software screenshot	Y	Y
18	Voice	Y	Y
19	Live Chat(CC)	Y	Y
20	Maintenance info	Y	Y
21	Special Features	11	10
22	Wide Coverage of Models	Y	Y
23	Strong Diagnostic	Y	Y
24	Remote Service	Y	Y
25	Online Information	Y	Y
26	Online Help	Y	Y
27	One-click Upgrade	Y	Y

How to Register and Active Launch X431 Pro Mini?

User registration
Tap “Login” on the upper right corner of the main menu screen:

If you are a new user, tap “New Registration”. See below picture.

Note: To obtain better service, you need to provide real information.
Create App account: fill in the information in each field and then tap “Register”, a screen similar to the following will appear:

Activate the VCI module:
In the above figure, input the Serial Number and Activation Code, which can be found in the password envelope.

Note: To exit and activate it later, tap “Skip”. In this case, you can activate your connector by tapping “Activate Connector” in “Personal Center”.
Tap “Activate”, a dialog box pops up saying congratulations! You have successfully completed your registration; the next step is to download the diagnostic software

X-431 PRO MINI whole set: X-431 PRO MINI is mainly composed of an X-431 PRO MINI handset, and a DBSCar II VCI module.

X-431 PRO MINI handset


1 VCI module
2 Reset hole
3 Rear camera
4 Camera flash
5 Slot for VCI module For housing the VCI module.
6 POWER/Screen lock key In Off mode, press it to turn X-431 PRO MINI on; In On mode, turn X-431 PRO MINI off with long press or lock screen with short press.
7 Carry strap
8 Air intake vent
9 USB/Charging port To connect to the power adaptor for charging.
10 Microphone
11 LCD screen
12 VOLUME +/- Key To adjust the volume. To print the screen, hold and press the POWER and VOLUME – key until a snapshot pops up on the screen.
The captured snapshot is saved in the “Screenshots” folder.
13 Speaker
14 Front camera
15 Earphone Jack

Launch X431 Pro Mini Reviews:

Package came fast.Called the customers service for TECH support and I was asked to offer them the serial number, country and language I would be needed for using the tool.after activation and downloading the sofware, found it is really a multi-function device with a wide car coverage list.I applied it to my Porsche, and it accurately solved the oil indicator and cleared the DTC. I also used it to troubleshoot problems of my wife’s Audi,couple of problems was found and fixed without issues.A good unit indeed.The seller was fairly supportive and the product good as well,I bet this product can at least save me $2000 plus time and labor per year. Highly recommend.

Launch X431 Pro Mini FAQ:

Question 1: Can this scanner program a new key?
Answer 1: Yes, this diagnostic tool can program a new key

Question 2: The caption says one year update and the description says two years. Most other sellers have two years of free updates. Which is offered here?
Answer 2: Dear sir, as for this diagnostic tool, we offer 2 years free update .

Question 3: Does this read OBD 1 cars?
Answer 3: yes, it can compatible with obd1, there are some old connectors to fit OBD1. and it covers many vehicles: BMW, Benz, GM, USA Ford, Chrysler, VW, Porsch, TOYOTA, VOLVO, Audi, Acura, Changan, Daweoo, Gaz, Hafei, Huachen, Jiao, Lexus, Xiali, Xinkai, Fiat, Holden, Maruti, Opel, Peugeot, Saab, Ssangyong, Tata, Changhe, Flyer, GMSA, Infiniti, Mahindra, Perodua, Proton, Qirui, TlIsuzu, Zhongshun, EOBD2, Euroford, Jagar, Renault, Smart, Sprinter, VAZ, Changcheng, Dacia, Ford, HaoQing, Jinlong, Liuwei, Rover, ZhongTai, ZhongXing, Bxfiat, HM, Isuzu, Jacty, JPIsuzu, MAZDA, Seat, Skoda, SUZUKI, Daihatsu, Mitsubishi, Citroen, Hyundai, Kia, Lancia, Landrover, Nissan, Romeo, Subaru.

Question 4:How to handle when you encounter “Insufficient storage space”?
Answer 4:If this happens while downloading the diagnostic software, please proceed as follows:
1. Get your X-431 PRO MINI username and password ready. If you forgot thepassword, please dial our hotline to retrieve it with the product serial number 98539*******.
2. Reset the X-431 PRO MINI to the default factory settings (For details, please refer to Item 5 in this Chapter).
3. Tap “Settings” --> “WLAN”, choose the desired WLAN network to connect.
4. Open the browser and visit www.dbscar.com to download and install the latest App.
5. After the installation is complete, launch the application and login with your username and password.
6. Tap --> “Update” to download the diagnostic software.
Note: For new App, the software structure and storage space occupied by the vehicle softwares have been optimized so as to avoid the occurrence of insufficient storage.

Question 5:Why some videos on the website can be not played?
Answer 5:It possibly results from:
1. The current browser does not support Flash playing;
2. Flash player does not support this video.Try to use other browsers to watch it or install other Flash player.

Question 6:The date and time of X-431 PRO MINI cannot be set.
Answer 6:It is because Automatic date & time is set on your X-431 PRO MINI. Tap “Settings” --> “Date & time”, deselect “Automatic date & time” and then set the date and time manually. Since the diagnostic reports are saved and sorted by date, please make sure the system date and time is properly configured on this tool.

Launch X431 Pro Mini Technical Parameters:
Operating system: Android 5.1
Processor : Quad core 1.3 GHz
Memory: 2 GB
Storage: 16GB
LCD screen: 6.9 inch with a resolution of 1280 x 720 pixels
Camera : Front-facing 2MP camera + rear-facing 5MP camera
Battery : 3.7V/3000mh rechargeable polymer lithium battery
Connectivity : Wi-Fi: WLAN 802.11b/g/n ，Bluetooth: Bluetooth 4.1
Working temperature: 0℃ ~ 45℃
Storage temperature: -10℃ ~ 50℃

VCI module:
Working voltage 9 ~18V
Average working current About 85mA
Standby current About 55mA
Working temperature -10℃ ~ 55℃
Storage temperature -20℃ ~ 70℃
Relative humidity 20% ~ 90%

DBScarⅢ Adapter:
Size: 69 × 40 × 18 mm
Operating voltage: 9V DC - 18V DC
Test voltage: DC12V
Typical power consumption: ≤2W
Bluetooth distance: 100 m
Connectivity: Bluetooth + wired
Operating temperature: -10℃to 50℃
Red Indicator: Turns red when connected to power supply;
blue Indicator: Turns blue then wireless Bluetooth work;
USB work: Turns green when the connector is connected to the USB cable

Launch X431 Pro Mini Package Includes:

1pc x X-431 PRO MINI tablet
1pc x Password envelope
1pc x VCI module (For connecting OBD II vehicles)
1pc x OBD II extension cable
1pc x OBD I adaptor (For connecting the non-16pin diagnostic connector and the
VCI module)
1pc x Battery clamps cable
1pc x Power adaptors
1pc x Non-16pin connectors (For connecting non-OBD II vehicle)
